MR-J2-CT Setup Software FWS-B05B023 设置程序下载

[复制链接]
bluesky1 发表于 2024-7-7 11:55:48 | 显示全部楼层 |阅读模式
安装文件下载:注意:很老的软件了,仅供个人在家测试用途,具体系统兼容性和安装方法请自行查阅资料,文件来源于网络搜集可靠性安全性完整性稳定性都无法验证,禁止用于其他用途,否则后果自负。
MR-J2-CT Setup Software FWS-B05B023.zip (2.21 MB, 售价: 80 E币)

Personal computer        CPU more than Pentium133MHz. Below OS is operable.
RAM: More than 32MB   Hard disk:3MB free space  Serial port use.
OS        Windows2000、Windows Me、Windows98 (Note 1)
Display        More than 640×400 color, or 16 gradation monochrome, and can be used for above OS.
Keyboard        Connectable to the personal computer.
Mouse        Usable to above OS.  However the serial mouse is not used.
Printer        Usable to above OS.
Communication cable        MR-CPC98CBL3M、MR-CPCATCBL3M
Make it referring to the MR-J2-CT instruction manual when those are not used.
(Note 1) Windows is the registered trademark of Microsoft Corporation.

Model        Japanese:FWS-B02B022
English  :FWS-B05B023
Communication signal        RS-232C comply
Communication speed        9600bps
Monitor        Group display, High-speed display, Graphic display
Alarm        Alarm display, Alarm history
Diagnosis        I/O signal display, Power supply ON cumulative display, Auto turning condition display, Absolute position monitor, Unit information
Parameter        Data setting chart display, Modification list display, Detailed information display
Test operation        Auto operation, Manual operation, JOG operation, Reference point return, Absolute position standard position setting
File operation        Data writing, Save, Print
